Straub pipe repair clamps available with free delivery Australia wide*. We supply Straub pipe repair clamps to all cities in Australia, Perth, Adelaide, Melbourne, Sydney, Brisbane, Darwin, Canberra and Hobart.

We are a professional supplier of Straub pipe repair clamp products in Australia. Contact us for more information on the Straub clamp range of products.

Straub clamp facts:

• Straub have over 50 years of experience manufacturing pipe repair clamps and have a global reputation.
• Straub are manufactured in Switzerland and were the first brand on the market more than half of a century ago.
• There are 3 different models of Straub pipe repair clamps available in a range of sizes, materials and pressure ratings. We can supply all 3 different models which include the Straub Open-Flex range, SCE Clamp range and SCZ Clamp range.
• Straub repair clamps available in size range 44.0mm to 4064.0mm.

General information on Straub pipe repair clamps:

• The Straub pipe repair clamp range is the SCE and SCZ model. The Straub Open Flex coupling range can also be used as pipe repair clamps as they open and can wrap around a pipe just like a pipe repair clamp.
• The Straub SCE model has a size range of 44mm to 330mm pipe outside diameters. Pressure ratings of 16 Bar to 10 Bar.
• The Straub SCZ model is a two part casing model and has a size range of 88mm to 440mm pipe outside diameters. Pressure ratings of 16 Bar to 5 Bar.
• The Straub Open Flex range is available in sizes from 48.3mm to 4064.0mm.
• The casing material of the Straub clamps is 304 stainless steel, with an NBR sealing sleeve. EPDM rubber sealing sleeves are available on request. Straub Open Flex products are available in 316 stainless steel and hot dip galvanised.
• The Straub clamps will suit all pipe materials and are axially flexible.
• No special tools are required, just a torque wrench.
• The radial length of the damaged area must not be greater than 20% of the pipe outside diameter. For example 219.1mm divide by 5 is 43.82mm. So the maximum radial damage on a 219.1mm outside diameter pipe must not be greater than 43.82mm.

The purpose of Straub pipe repair clamps:

• Straub pipe repair clamps are designed to wrap around pipes, to stop and seal the leakage of fluid or gas from a hole, crack or because of pipe corrosion.
• Can offer permanent and temporary repair.
• Easy to use and install, providing a fast solution.
• Can be used on pipes above or below ground, and under water.
• The rubber lining provides a 100% seal around the full circumference of the pipe.

The table below provides a quick overview of the Straub pipe repair clamp range of products:

Model	Size range	Width range	Pressure rating range
Straub Clamp SCE	44.0mm to 320.0mm	200mm to 400mm wide	16 Bar to 10 Bar
Straub Clamp SCZ	88.0mm to 440.0mm	200mm to 400mm wide	16 Bar to 5 Bar
Straub Open Flex 1L	48.3mm to 168.3mm	75mm to 107mm wide	25 Bar to 16 Bar
Straub Open Flex 2	172.0mm to 2032.0mm	138mm to 148mm wide	25 Bar to 2 Bar
Straub Open Flex 3	219.1mm to 4064.0mm	210mm to 218mm wide	25 Bar to 1 Bar
Straub Open Flex 3.5	323.9mm to 4064.0mm	310mm to 311mm wide	25 Bar to 1 Bar
Straub Open Flex 4	323.9mm to 4064.0mm	443mm to 444mm wide	25 Bar to 1 Bar
Straub Open Flex 1L GT	73.0mm to 168.3mm	94mm to 107mm wide	16 Bar to 16 Bar



How to install a Straub pipe repair clamp:

1. Determine where the hole, crack or corrosion is on the pipe, and determine the width of clamp required to fully cover the damaged area. Assuming the outside diameter of the pipe has already been determined.
2. Clean the area on the pipe where the clamp will be clamping around, to ensure the clamp will fully seal and stop the leak. Using a heavy duty rag and wire brush should be sufficient.
3. Using a permanent marker, mark the clamp width on the pipe, ensuring that the damage on the pipe is in the centre of the pipe repair clamp. All damage must be in the centre of the pipe repair clamp.
4. Some pipe materials will require a lubricant to be spread over the rubber seal on the inside of the pipe repair clamp, to ensure the rubber seal doesnt get damaged during installation.
5. Open the pipe repair clamp, and wrap around the pipe as close to the damage as possible.
6. Loosely tighten the bolts on the clamp, so that you can quickly slide the clamp over the damaged area between your line markings you made.
7. As quickly as possible, when the clamp is in position, start to tighten the bolts with a torque wrench, starting with the middle bolt(s) and working outwards.
8. Torque all bolts to the required torque mentioned on the label of the pipe repair clamp.

Note: Always install a Straub pipe repair clamp centred over the crack or hole in the pipe. This will ensure the greatest chance of a 100% seal with zero leakage.

Orbit Pipe Repair Clamp products are available with free delivery Australia wide*. We supply Orbit pipe clamps to all cities in Australia, Perth, Adelaide, Melbourne, Sydney, Brisbane, Darwin, Canberra, Hobart and more.

We can supply pipe repair clamps to suit almost any application with a range suitable for very narrow locations, very long cracks in pipes requiring wide clamps, high pressure applications, chemical applications, and leaking bell joint connections.

WRAS approved EPDM rubber for potable water use.

Looking for something else? We have a wide range of check valves, duckbill valves, pipe couplings, Y Strainers, and more.

Pipe Repair Clamps

Orbit Couplings have a range of 16 different pipe repair clamp models such as the economical Repair Clamp available in different lengths upto 400mm long. The Elbow Repair Clamp which is a great clamp for pipe elbows, the Flex Grip Open, Flex Grip 2 and Open Flex 400-L are good for both repair clamp use and pipe coupling use as well as for high pressure applications.

The table below shows an overview of the Orbit Pipe Repair Clamp product range:

Model	Size range	Pressure rating range
Orbit Flex Grip Open S	20.0mm to 355.6mm	32 Bar to 8 Bar
Orbit Flex Grip Open L	32.0mm to 355.6mm	32 Bar to 8 Bar
Orbit Flex Grip 2 S -  4 S	20.0mm to 4064.0mm	32 Bar to 2.5 Bar
Orbit Flex Grip 2 L -  4 L	20.0mm to 4064.0mm	32 Bar - 2.5 Bar
Orbit Elbow Repair Clamp	15.8mm to 508.0mm	40 Bar to 9 Bar
Orbit Repair Clamp 55mm wide	48.3mm to 57.0mm	16 Bar to 16 Bar
Orbit Repair Clamp 200mm wide	48.3mm to 280.0mm	16 Bar to 10 Bar
Orbit Repair Clamp 300mm wide - single casing model	48.3mm to 330.0mm	16 Bar to 10 Bar
Orbit Repair Clamp 300mm wide - double casing model	88.0mm to 367.0mm	16 Bar to 10 Bar
Orbit Repair Clamp 400mm wide - single casing model	88.0mm to 330.0mm	16 Bar to 10 Bar
Orbit Repair Clamp 400mm wide - double casing model	88.0mm to 440.0mm	16 Bar to 10 Bar
Orbit Open Flex 400-L	200.0mm to 1524.0mm	24 Bar to 5 Bar
Orbit Open Flex 300-L	200.0mm to 1524.0mm	25 Bar to 5 Bar
Orbit Open Flex 200-L	148.0mm to 2010.0mm	25 Bar to 2 Bar
Orbit Universal Dual Clamp	88.0mm to 328.0mm	16 Bar
Orbit Encapsulating Pipe Repair Clamp	92.0mm to 1678.0mm	25 Bar to 16 Bar

Test Pressure = Bar x 1.5

Facts about Orbit pipe repair clamps:

• Orbit pipe repair clamps have been on the Australian market since 2015
• Orbit pipe repair clamps are widely used in Australia and parts of Asia
• Orbit pipe repair clamps are assembled in Australia
• Orbit Couplings manufacture 13 different models of clamps for pipe repair solutions.
• Orbit Couplings can manufacture small orders in 3 working days, and large orders in 7 to 10 days

General information on Orbit pipe repair clamps:

• Orbit pipe repair clamps solve many problems such as circumferential breaks, corrosion holes, impact damage, and longitudinal cracks in pipes. The repair clamp when fitted around the problem will provide a reliable seal to a wide range of pipe materials and outside diameter sizes.
• All pipe repair clamp products are designed to be fitted to the outside of a pipe, without any pipe removal or disassembly.
• All repair clamp products are designed to allow for pipe movement.
• Teflon coated bolts protect the stainless steel bolt threads, and allow for smooth nut tightening.
• Rubber materials such as Viton and Silicone will allow for special application requirements.

The purpose of Orbit pipe repair clamps:

• Pipes get old and start to crack, develop holes, and corrode, and cause a loss of fluid or gas leakage through these pipe problems. A fast solution to stop the loss of fluid or gas is to fit an Orbit repair clamp, providing a durable long lasting seal.
• Pipes can also be damaged during installation, or some other mishap, and the quickest solution can be to install a pipe repair clamp to fix the problem.
• Welding pipes can often be dangerous or impossible to do in certain circumstances, and welding can usually cause more problems years later, where the last solution is to fit a pipe repair clamp.
• Manufacturing the clamps from Stainless Steel and rubber, ensures that no further corrosion will occur, or will be minimised as much as possible.
• A pipe repair clamp provides a full seal around the full circumference of the pipe, covering the width of the clamp as well, acting similar to the pipe shape design for pressure allowance.

Selecting the correct length for a pipe repair clamp:

• It is important that where ever possible, the length of a pipe repair clamp should be the same as the outside diameter of the pipe. For example if the outside diameter of the pipe is 323.9mm, then the length of the pipe repair clamp should be approximately 300mm.
• There will be circumstances where the length cannot be the same as the pipe outside diameter. Such as any pipe outside diameter larger than 400.0mm, as our longest clamp is 400mm long.
• If you have a pipe with an outside diameter of 200.0mm, but a crack or pipe rupture which is 100mm long, then a 200mm long clamp will not be safe to use, and you will need a longer clamp such as 300mm or 400mm long.
• The recommended rule for selecting a pipe clamp length for sealing a pipe with a pipe crack or pipe rupture, is to measure the length of the crack or rupture at its longest length, and multiply this length by 3. So for example, if the crack or rupture is 100mm long, 100mm x 3 = 300mm. So the minimum length of the pipe repair clamp should be 300mm.
• It is also important to remember that the radial length of a hole or crack, should only be a maximum of 20% of the outside diameter, when a pipe repair clamp is recommended. If the radial length of the hole or crack is greater than 20% of the pipe outside diameter, the section of pipe will need to be removed, and replaced.

How to install an Orbit pipe repair clamp:

1. When installing a pipe repair clamp, always ensure the pipe outside diameter has been measured, to ensure the correct size of clamp is going to be installed.
2. Clean the surface of the pipe where the clamp is going to fit over, this ensures the rubber gasket seal will have good contact with the pipe for sealing a 100% tight seal with zero leakage.
3. Next using a permanent marker pen and a tape measure, firstly measure the width of the repair clamp onto the pipe, with the middle of the crack or hole in the middle of this length measured and mark on the pipe two outer lines. This will help the installer to remember where the hole or crack is once the clamp is wrapped over the pipe, before tightening the bolts.
4. Before wrapping the clamp around the pipe, lubricate the rubber gasket and pipe, this could be done quickly with a paint brush to apply the lubricant with.
5. Open the pipe repair clamp and wrap it around the pipe, and quickly tighthen the bolts.
6. Tighten the middle bolt or bolts first, and work your way out to the outer bolts. Tighten to the torque stated on the clamp label. Never exceed the maximum bolt tightness mentioned on the product label.
7. Check the bolt tightness with a torque wrench 30 minutes after the clamp has been in use.

Encapsulating Pipe Repair Clamp available with free delivery Australia wide*. Also known as a Split Barrel pipe repair clamp, Pressure Containment clamp and Split Sleeve repair clamp.



The encapsulating pipe repair clamp is available in a range of sizes to suit pipe outside diameters from 87.0mm to 1678.0mm. This model of repair clamp is used to fix leaking bell joint connections without removing a pipe or a connection. The clamp comes in two parts and is installed and fitted around the outside of the leaking pipe or joint. The clamp is compatible with all pipe materials. The clamp allows for pipe movements avoiding possible breakages.

These pipe clamps have a ductile cast iron casing, with an EPDM or NBR rubber seal gasket. The clamps are tested to 1600kPa pressure for all sizes. These clamps have an OD tolerance starting from -2mm to +2mm depending on the size of the clamp. The seal of the clamp works by using a progressive lip seal system, which uses internal fluid pressure to help the sealing effect.

When installing this clamp, ensure the correct outside diameter has been measured, clean the surface of the pipe all over the area where the clamp will be fitted.

Measure the width of the clamp, and mark the length with a permanent marker and tape measure onto the pipe, and an equal distance from the centre of the crack or hole. This will remind you once the clamp is wrapped around the pipe, exactly where to line it up to ensuring the best effect on sealing the hole or crack.

The vent plug should be removed before installing the clamp, as this allows the fluid to be vented out whilst installation is taking place. The vent plug should be the very last part to be fitted and tightened during the installation process.

Start by tightening the middle nuts and bolts first, ending with the outer nuts and bolts. Fasten the nuts and bolts to the required torque mentioned on the clamp itself.

Finally, after 30 minutes of the clamp being in use, check the tightness again with your torque wrench.

Teekay Repair Clamps and Repair Couplings are available in Australia with free delivery*. We supply Teekay Repair Coupling and Teekay Repair Clamp products to all cities in Australia, Perth, Adelaide, Melbourne, Sydney, Brisbane, Canberra, Darwin and Hobart.

We are a professional supplier of Teekay Repair Clamps in Australia. Contact us for more information on Teekay pipe repair clamp products.

Teekay Couplings manufacture a wide range of pipe repair clamps and repair couplings.

Two solutions - Repair Coupling model, Repair Clamp model

Size range up to 3000mm OD

Width range up to 410mm wide

Once the clamp has been wrapped around the pipe, the pipe fitter can install the clamp the same way as a pipe coupling using a torque wrench.

No need to turn off the water, as the clamp can be fitted on filled pipelines.

Suitable for emergency repairs of leaking pipes. Stop leaking pipes in 2 minutes and reduce down time.

Light weight stainless steel design, casing material options are 304 stainless steel and 316 stainless steel.

Gasket material options are EPDM, NBR, HNBR, VITON.

Gasket design actively seals onto the pipe.

Applications include Water, Process, Oil and Gas and Marine Industries.

Contact us for more information on pipe repair clamps by Teekay.





When do you need a pipe repair clamp?

• Do you have a leaking pipe and want to seal the leak easily? You need a pipe repair clamp.

We are suppliers of Orbit Pipe Repair Clamps, Straub Pipe Repair Clamps and Teekay Repair Clamps.

Facts about a Stainless Steel Pipe Repair Clamp:

• A pipe repair clamp, is simply a clamp, usually manufactured from 316 grade stainless steel, manufactured to the circular shape of a round pipe matching the specific outside diameter of the pipe which needs to be sealed.

• The clamp has a rubber sealing sleeve fitted on the inside of the clamp, it is this rubber seal which seals the leaking pipe.

• The clamp casing provides the strength and keeps the clamp in position once the bolts have been tightened.​

Selecting the correct width of a pipe repair clamp:

• Where ever possible, the width of the clamp should always match the outside diameter of the pipe. For example, if the pipe outside diameter is 300.0mm, then the width of the clamp should be 300mm as an absolute minimum.

• If the crack in the pipe is 200mm long, multiply 200mm x 3 = 600mm. The clamp should be at least 600mm wide if a crack is 200mm long.

Why use pipe repair clamps?

• Pipe clamps are a valuable part of any water system repairs kit. Whilst repairs or alterations are being done, the clamp keeps the pipes steady. They fit snugly to the pipe, securing it so that even the smallest and most minute repairs to broken, damaged, leaky, or corroded pipes can be conducted more easily.
• We stock pipe repair clamps from leading brands such as Teekay, Orbit, and Straub, using the best materials to ensure that our products meet your expectations every time.
• Need help choosing the right fit? Speak to our team today.

Shipping pipe repair clamps to Sydney, Brisbane, Melbourne, Adelaide and more.

Conducting repairs on water systems and other industries that use pipes can be a fiddly process. Whether you’re a seasoned DIY plumber who wants to grab a few tools of the trade, or you’re an experienced professional repairperson, Dewater Products has the biggest range of spare parts and accessories for you. Our pipe clamps are used by people from across Australia, from Sydney, Adelaide, Brisbane, Melbourne and beyond.

Learn why we’re Australia’s trusted suppliers of water system parts and accessories by chatting to our team.

Based in Sydney, Brisbane, Adelaide or beyond? we ship to you

When you need a reliable supplier of pipe repair clamps, order your parts from Dewater Products. An Australian company based in Perth, we have been providing companies with high quality pipe repair clamps, rubber expansion joints, pipe couplings, and more. Our products are sought after by companies nationwide; regardless of where you’re located in Sydney, Adelaide, Brisbane, or Melbourne, your order will be shipped to your workshop as soon as possible. Want to learn more about our pipe repair clamps or something else in our range? Contact us on 1300 271 290 to speak to one of our friendly team members.
